BRAVO 40 | 40 Amp MPPT Solar Charge Controller
Charge Controllers

BRAVO 40 | 40 Amp MPPT Solar Charge Controller

SKU: RS-MPPT40P
$159.99 / Each
✓ In Stock (25 available)

BRAVO 40 | 40 Amp MPPT Solar Charge Controller

View Kit Bundles
🌾

Why Buy This from AOG

✓Authorized dealer — genuine product, backed by the manufacturer's warranty
✓Personal service from a small, family-run business that knows and serves the Plain & off-grid community — not a faceless call center
✓Chosen to last, not to be the cheapest — built for years of real use
✓Curated for true off-grid living, not stacked on a big-box shelf

Need something else too?

Solar Panels | Kits & Bundles | Batteries | Inverters | Power Converters | DC-DC Chargers | Chargers | Solar Racking & Mounting | Wiring & Connectors | Off-Grid Appliances | Lighting & Accessories | Monitoring & Accessories | Parts & Repair | Misc | Power Controllers

Shipping Info
Weight: 0lb 0oz
Dimensions: 0.00" × 0.00" × 0.00"

Ships to the lower 48 states. See our Shipping & Returns policy before you buy.

Key Features

• MPPT
• Tracking Efficiency Above 99.5%
• Charge Conversion Efficiency as high as 98%
• 12V/24V DC System Self-Adaptation
• Reverse Discharge Protection
• Targeted for Accuracy
• Overvoltage Protection
• Common Negative Connection
• Charging Data Storage
• Conformal Coating For Inside Board
• In-house Design And Manufacture
• Extensive Internal Electronics, In-Circuit Protections, And Safety Protections
• Targeted For Lead Acid Batteries: Gel, AGM, WET, CRYSTAL, CALCIUM Batteries Type Selections
• Targeted For Lithium Batteries: LiFePO4, LTO (Lithium Titanium Oxide), LCO Batteries Type Selections
• Certified to UL 1741

Specifications

• System Nominal Voltage: 12/24V Auto
• Max. PV Open Circuit Voltage: 100V DC
• Charging Technology: MPPT
• Max PV Charging Current: 40A
• Max. Recommended PV Input Power: 600 Watt (12V) / 1200 Watt (24V)
• Charge Conversion Efficiency: ≤98%
• MPPT Tracking Efficiency: >99.5%
• Battery Type Preset: Crystal, Gel, AGM, WET, Calcium / LCO, LFP, LTO
• Housing Case Color: Black / Grey
• IP Grade: IP43 for Inside PCBA, IP22 for Connection Area
• Net Weight: 1.17kg / 2.58lb
• Dimensions (L*W*H): 195*142*74 mm / 7.7*5.5*2.9 in
