Home/ Shop/ Charge Controllers/ BRAVO PRO 40 | Premium 40A 12V/24V MPPT Flush Mount Solar Controller for RVs, Trailers, Campers, Vans, Boats, Off-Grid | With Bluetooth | UL1741 Certified
BRAVO PRO 40 | Premium 40A 12V/24V MPPT Flush Mount Solar Controller for RVs, Trailers, Campers, Vans, Boats, Off-Grid | With Bluetooth | UL1741 Certified
Charge Controllers

BRAVO PRO 40 | Premium 40A 12V/24V MPPT Flush Mount Solar Controller for RVs, Trailers, Campers, Vans, Boats, Off-Grid | With Bluetooth | UL1741 Certified

SKU: RS-MPPT40FB
$249.99 / Each
✓ In Stock (25 available)

Features High-Efficiency MPPT Charging 99.5% MPPT Tracking Efficiency – Maximizes available solar energy harvest 98% Conversion Efficiency – Reduces power loss for higher system ef

View Kit Bundles
🌾

Why Buy This from AOG

✓Authorized dealer — genuine product, backed by the manufacturer's warranty
✓Personal service from a small, family-run business that knows and serves the Plain & off-grid community — not a faceless call center
✓Chosen to last, not to be the cheapest — built for years of real use
✓Curated for true off-grid living, not stacked on a big-box shelf

Need something else too?

Solar Panels | Kits & Bundles | Batteries | Inverters | Power Converters | DC-DC Chargers | Chargers | Solar Racking & Mounting | Wiring & Connectors | Off-Grid Appliances | Lighting & Accessories | Monitoring & Accessories | Parts & Repair | Misc | Power Controllers

Shipping Info
Weight: 2lb 0oz
Dimensions: 0.00" × 0.00" × 0.00"

Ships to the lower 48 states. See our Shipping & Returns policy before you buy.

Key Features

• 99.5% MPPT Tracking Efficiency – Maximizes available solar energy harvest
• 98% Conversion Efficiency – Reduces power loss for higher system efficiency
• Auto 12V / 24V Detection – Simplifies installation and setup
• Wide Battery Compatibility – Supports GEL, AGM, WET, CALCIUM, LiFePO ₄ , LTO, and LCO
• LCD Display – Real-time system status at a glance
• Bluetooth + App Support – Remote monitoring and parameter adjustment via smartphone
• Multi-Level Safety Protection – Protects against over-voltage, reverse polarity, short circuits, and overheating
• Certified Safety & Compliance – UL1741 , CE, FCC, RoHS

Specifications

• System Nominal Voltage : 12V/24V Auto
• Maximum Solar Input Current: 40A
• Maximum Charging Current: 40A
• Recommended Solar Input Power: 600W(12V)/1200W(24V)
• Solar Input Voltage Range: 8-100V
• Standby Current: 10mA
• Charging Technology: MPPT
• MPPT Voltage Tracking Range: 15-72VDC
• MPPT Efficiency : 99.5%
• Conversion Efficiency: 98%
• Battery Compatibility: GEL / AGM / WET / LFP / LTO / LCO / Crystal / Calcium / Customizable Battery
• IP Grade: IP43
• Operating Temperature: -13℉ ~ 122℉
• Bluetooth: Yes
• Options: External Battery Temperature Sensor; External Digital Remote Display
• Dimensions: 8.3 × 6.1 × 2.2 in
• Weight: 1.8 lb
• Certifications: UL1741, CE, FCC, RoHS
